CelloPure CM

Ion Exchange Chromatography Media

Introduction

CelloPure CM

CelloPure CM is a weak cation exchanger chromatography media based on spherical particles manufactured from crosslinked cellulose. Each offers excellent flow properties, mechanical stability, and chemical resistance. In this ion exchange resin, the Carboxymethyl (CM) functional group is attached to the cellulose beads, which remains charged and maintains consistently high capacity over the entire working range, pH 2 to 12. These ion exchangers are ideally suited for both laboratory and process scale chromatography of proteins, peptides, and other biomolecules.

micrograph_cellopure_cm

Optical micrograph of CelloPure CM

CelloPure CM base resin

Cross-linked spherical Cellulose beads are prepared by unique process from crystalline natural polysaccharides, differing the physical characteristics from noncrystalline polysaccharides such as agarose. Thus, CelloPure resins are highly porous in nature (Fig.). Due to that porous nature of the highly cross-linked spherical cellulose bead, resins have unique mechanical strength. CelloPure CM, made from highly crosslinked cellulose beads, benefits from this structure by offering unique mechanical strength and efficient flow velocity for large biomolecules. This helps improve performance when purifying large proteins and other biological substances.

Dynamic Binding Capacities of CelloPure CM

CelloPure CM have high efficiency in mass transfer and excellent Dynamic Binding Capacities, particularly for large biomolecules like Immunoglobulins (IgG) also for HSA (Human Normal Albumin) and Lysozyme, Ribonuclease. Because of these special qualities, CelloPure CM media can be used in downstream processes in the purification of biopharmaceuticals. With good reliability, protein separation has been scaled up using CelloPure CM from laboratory size and no discernible variations were seen in the purity of single peak at the time of protein separation.

  • Column : HiScale 16, 5 cm bed height, 10 ml bed volume
  • Flow rate : 1ml/min
  • Sample : 1-2mg/ml
  • Start Buffer : 0.25M Sodium Acetate (pH 5.6) for IgG 50mM Tris-HCL (pH 8.5) for Lysozyme
  • Elution Buffer : 0.25M Sodium Acetate + 0.5M Nacl (pH 5.6) for IgG 50mM Tris-HCL + 1M Nacl (pH 8.5) for Lysozyme
CelloPure CM Resin 100 mL
CelloPure CM Resin, 100 mL
High-performance resin for efficient biomolecule separation.
CP-CM-100ML
On Request
CelloPure CM Resin, 50 mL
High-performance resin for efficient biomolecule separation.
CP-CM-50ML
On Request
Pack Size
100 mL
50 mL

Table 1. Basic characteristics of CelloPure CM weak cation exchange chromatography media

Attribute CelloPure CM Resin
Ion Exchange Type (Functional Group) Carboxymethyl group
Base Matrix Spherical, Cross-linked Cellulose Beads
Particle Size (μm) 40-130 µm
pH Working Range 2 to 11
Operating Pressure Up to 2 bar (0.2 MPa)
Ion Exchange Capacity (meq/ml-gel) 0.09-0.14
Dynamic Binding Capacity (mg/ml) Human IgG 60
Lysozyme 145
Supplied Suspension in 20% Ethanol

Applications

CelloPure CM, CelloPure+ CM and GeloPure CM finds application in various bioseparation techniques:

Advantages

Disadvantages
